Laravel gRPC Client on Docker

參考資訊

系統必要軟體

修改Dockerfile 增加以下，install grpc可能會跑超過1000秒以上需要一些時間

#grpc
RUN pecl install grpc
RUN pecl install protobuf
RUN apt-get install -yq protobuf-compiler

#grpc

RUN pecl install grpc

RUN pecl install protobuf

RUN apt-get install -yq protobuf-compiler

修改php.ini，增加以下extension

extension=grpc.so
extension=protobuf.so

1 2	extension=grpc.so extension=protobuf.so

專案套件

Laravel 專案中安裝以下套件

composer require grpc/grpc
composer require google/protobuf
composer require ext-grpc

composer require grpc/grpc

composer require google/protobuf

composer require ext-grpc

gRPC資料準備

準備gRPC server端提供的proto 檔案，範例如下

#notify_rpc.proto
syntax = "proto3";

//package name
package Notify;

//service name
service Notifier {
  //function name
  rpc send_message (NotifyRequest) returns (NotifyResponse);
}

//method1
message NotifyRequest {
  string message = 1;
  string platform = 2;
}

//method2
message NotifyResponse {
  string message = 1;
}

#notify_rpc.proto

syntax = "proto3";

//package name

package Notify;

//service name

service Notifier {

//function name

rpc send_message (NotifyRequest) returns (NotifyResponse);

}

//method1

message NotifyRequest {

string message = 1;

string platform = 2;

}

//method2

message NotifyResponse {

string message = 1;

}

在專案資料夾中建立以下資料夾

protobuf/build

protobuf/src

將notify_rpc.proto檔案放到protobuf/src中

執行以下指令生成相對應的php檔案

protoc --proto_path=protobuf --php_out=protobuf/build protobuf/src/notify_rpc.proto

1	protoc --proto_path=protobuf --php_out=protobuf/build protobuf/src/notify_rpc.proto

–php_out指定生成的位置

最後一個參數告訴他proto檔案的位置在哪

這時候會看到專案資料夾/protobuf/build中產生了以下幾個檔案

GPBMetadata/Src/NotifyRpc.php
Notify/NotifyRequest.php
Notify/NotifyResponse.php

GPBMetadata/Src/NotifyRpc.php

Notify/NotifyRequest.php

Notify/NotifyResponse.php

根據外部連結的說明文件來看，我們還缺一個 Nofity/NotifyClient.php檔案，原因是還需要透過grpc_php_plugin來生成，但是這個plugin一直build不起來

不過NofityClient.php不難，就手刻一個

<?php
//namespace 與NofityRequest.php中相同
namespace Notify;

class NotifyClient extends \Grpc\BaseStub {

public function __construct($hostname, $opts, $channel = null) {
parent::__construct($hostname, $opts, $channel);
}

//send_message就是proto檔案中定義的，傳入值為NofityRequest，回傳值為NofityResponse
public function send_message(\Notify\NotifyRequest $argument,
$metadata = [], $options = []) {
return $this->_simpleRequest('/Notify.Notifier/send_message',
$argument,
['\Notify\NotifyResponse', 'decode'],
$metadata, $options);
}
}

<?php

//namespace 與NofityRequest.php中相同

namespace Notify;

class NotifyClient extends \Grpc\BaseStub {

public function __construct($hostname, $opts, $channel = null) {

parent::__construct($hostname, $opts, $channel);

}

//send_message就是proto檔案中定義的，傳入值為NofityRequest，回傳值為NofityResponse

public function send_message(\Notify\NotifyRequest $argument,

$metadata = [], $options = []) {

return $this->_simpleRequest('/Notify.Notifier/send_message',

$argument,

['\Notify\NotifyResponse', 'decode'],

$metadata, $options);

}

gRPC服務呼叫

完成以上設定後就可以在Controller中呼叫Notify gRPC服務，範例如下

<?php

namespace App\Http\Controllers;

use Illuminate\Http\Request;
use Notify\NotifyRequest;
use Notify\NotifyClient;
use Grpc\ChannelCredentials;

class IndexController extends Controller
{
    //
    public function index(){

        //grpc_test
        $client = new NotifyClient('GRPC_SERVER_IP:PORT',[
            'credentials' => ChannelCredentials::createInsecure(),
        ]);
        $request = new NotifyRequest();
        //將需要傳送的兩個參數分別透過setMessage以及setPlatform加入
        $request->setMessage('hello123');
        $request->setPlatform('slack');
        $get = $client->send_message($request)->wait();

        return view('index');
    }
}

<?php

namespace App\Http\Controllers;

use Illuminate\Http\Request;

use Notify\NotifyRequest;

use Notify\NotifyClient;

use Grpc\ChannelCredentials;

class IndexController extends Controller

{

public function index(){

//grpc_test

$client = new NotifyClient('GRPC_SERVER_IP:PORT',[

'credentials' => ChannelCredentials::createInsecure(),

]);

$request = new NotifyRequest();

//將需要傳送的兩個參數分別透過setMessage以及setPlatform加入

$request->setMessage('hello123');

$request->setPlatform('slack');

$get = $client->send_message($request)->wait();

return view('index');

}
