前言:
#

在開發系統的這段期間,我們寫了N支API,然而每個操作的動作都離不開Create, Update, Read, Delete 這些動作

為了加速以及更懶惰(誤),我們團隊討論出一個夠嚴謹也可以更快開發的架構

結構說明:
#

Controller : 作爲Api的入口也作為整個資料流程的控管,其他的事情都讓Service、Repository來處理

Model : 定義資料表內容、定義資料驗證規則、定義表與表之間的relation

Repository : 作為資料操作的動作定義,直接控制Model做資料存取

Dto們 : 作為資料傳遞的介面,嚴格定義傳入Controller或者傳入Service的資料結構,這樣做可以一定程度的避免錯誤

一切的開端:
#

當每個API都需要Create, Update, Read, Delete這些方法的時候,我們第一個想到的是

那就寫個抽象類別來繼承好了,這樣就可以把需要的方法都先定義好,大約可以解決6成以上重複性的原始碼

但是面臨的就是下一個問題,舉例來說每一次的Create如果沒有特別需要處理資料那麼都是從Controller中呼叫Reposiroty的Create function就結束了

這樣的話,是不是可以再寫的更簡單一些?

加速原則 :
#

相同的命名原則,讓開發可以更快

舉個簡單的例子先,如果我們要對Customer做Create,也就是新增一筆客戶資料

那麼資料流應該會長這樣子

CustomerController -> CustomerRepository(Create function) -> Customer Model (write data)

因此我們寫了一個BaseController,在其中定義好repository_name, model_name 以及Dto

而且預設就是跟Controller相同的名字,整理一下上述案例,在CustomerController中,我們只要繼承了BaseController就會擁有以下

CustomerRepository
CustomerModel
CreateCustomerDto <--- 以Create作為範例的話

為了要在Controller一初始化就把以上物件準備好,我們會需要用上之前提過的callAction

https://www.alvinchen.club/2025/06/09/laravelcontroller%e4%b8%ad%e7%9a%84callaction/

我們在BaseController中先定義幾件事情

private string $__model_root__ = 'App\\Models\\';  //存放Model的路徑
private string $__dto_root__ = 'App\\Core\\Repository\\';  //存放Dto的路徑
private BaseModel|Authenticatable $__main_model__;  //預設跟Controller同名的Model
private ?string $__dto__;  //需要用上的Dto 名字
private Repository $repo;  //預設跟Contrller同名的Repository
private string $name;  //預設就是Controller的名字

接著定義幾個init_開頭的function,用來初始化以上的變數內容

protected function init_start(): static
{
    $this->name = str_replace('Controller', '', class_basename(static::class));
    return $this;
}

protected function init_db_source(): static
{
    if (class_exists($this->__model_root__.$this->name)) {
        $this->__main_model__ = new ($this->__model_root__.$this->name);
        $this->repo = $this->repository($this->name);
    }

    return $this;
}

protected function init_dto(): static
{
    $this->__dto__ = match ($this->get_method())
    {
        'create' => "{$this->__dto_root__}{$this->name}\\Dtos\\Create{$this->name}Dto",
        'update' => "{$this->__dto_root__}{$this->name}\\Dtos\\Update{$this->name}Dto",
        'read_list' => ReadListParamsDto::class,
        default => Null
    };
    return $this;
}

簡單說明一下這幾個function,分別是一句Controller的名稱初始化name , main_model , repo , dto 等等這幾個變數

接著在我們覆寫掉callAction這個function,讓以上幾個function可以正確的執行過一次

public function callAction($method, $parameters)
{
    foreach (get_class_methods($this) as $method)
    {
        if (str_starts_with($method, 'init_'))
        {
            $this->{$method}
        }
    }

    return parent::callAction($method, $parameters);
}

以上這幾行,就是簡單的把init_開頭的function找到,然後透過動態呼叫全部執行一次

https://www.alvinchen.club/2025/06/13/php-%e5%8b%95%e6%85%8b%e5%91%bc%e5%8f%ab%e5%87%bd%e6%95%b8variable-functions%e8%88%87see/

那Repository做什麼用?
#

Repository作為直接操作Model進行資料存取的元件,我們也是做了一層抽象處理,這樣這樣一來基本的Create, Update, Delete, Read都可以描述完成

每個各別的Repository繼承後只要描述關於relation的部分就可以了,大致像這樣子

public function create(Dto $params, ?Model $model=Null, ?array $relation=Null): Model
{
    $payload = $params->to_array();
    $relations = $relation !== Null ? $relation : $this->__create_relations__;
    $model = $model ? new ($model) : $this->__model__;
    try{
        DB::beginTransaction();
        $instance = $model->create($payload);
        $this->_relation_processor($instance, $payload, $relations);
        $instance->load($relations);
        DB::commit();
        return $instance;
    }catch (Throwable $throwable)
    {
        DB::rollBack();
        throw new Exception("{$model}新增錯誤: {$throwable->getMessage()}");
    }
}

舉Create的例子來說,透過定義好的Dto傳入需要寫入的正確資料,然後讓relation_processor處理相關聯表單所需要寫入的資料

這麼一來,我們回到CustomerController的Create function中,就只剩下以下內容

public function create(Request $request): Model
{
    return $this->repo->create(new $this->__dto__(...$request->json()));
}

邏輯上是把傳入值塞入CreateCustomerDto中,如果這時候傳入的資料不是預期的欄位就會直接報錯

接著將new出來的CreateCustomerDto交給CustomerRepository的Create function處理

是不是變得有夠簡單好寫呢?
